Sapphire Windows

Sapphire WindowsSapphire UV and IR transmission properties in combination with ability to withstand harsh chemicals, high pressures and temperatures offer strong advantages for Fire and IR Detectors, protective windows and thermocouple protection sheaths for remote sensors and optics for harsh environments such oil well drilling, chemical processing and other industrial processes.



Sapphire Window Specification:



 Material

 Optical grade sapphire

 Orentation

 C-axis, or specify

 Diameter tolerance

 ±0.05 mm

 Thickness tolerance

 ±0.02mm

 Clear Aperture

 Central 90%

 Parallelism

 10 arc sec

 Flatness

 λ/4 per inch at 633nm

 Surface Quality

 40/20

 Sapphire Windows

Standard products- Sapphire Round Windows:



Part No.

Dia(mm)

T(mm)

SRW0602

6

2

SRW1003

10

3

SRW1203

12.7

3

SRW1503

15

3

SRW2003

20

3

SRW2503

25.4

3

SRW3005

30

5

SRW3805

38.1

5

SRW5005

50.8

5



Standard products- Sapphire Square Windows:



Part No.

H(mm)

L(mm)

T(mm)

SSW1003

10

10

3

SSW1203

12.7

12.7

3

SSW1503

15

15

3

SSW2003

20

20

3

SSW2503

25.4

25.4

3

SSW3005

30

30

5

SSW3805

38.1

38.1

5
